SVS Prime Pinnacle Speakers (Each)

World-Class Audio for Everyone
The ultimate expression of what SVS sought to create with the Prime Series loudspeakers is epitomized in Prime Pinnacle. Audiophile refinement and musicality without sacrificing wide dynamic range, deep, effortless bass and all the excitement of a world-class loudspeaker.

SVS acoustic engineers spent more time voicing Prime Pinnacle than any speaker in SVS history, in large part to create a loudspeaker that was equally suited to meet the demands of both discerning audiophiles and hardcore home theater fans. To go even further, Prime Pinnacle’s cabinet design was made to blend seamlessly and sound amazing in any listening environment.

World-class performance in both a two-channel HiFi stereo or an immersive home theater surround sound system, Prime Pinnacle is unrivaled in its class and well-beyond.

FEATURES

• All-New 5.25" Midrange Driver with Composite Glass-Fiber Cone
• Premium 1” Aluminum Dome Tweeter
• Trio of 6.5” High-Performance Woofers
• Three Unique Port Tuning Frequencies
• SVS SoundMatch 3-Way Crossover

TECHNICAL SPECS

• Rated bandwidth: 29 Hz-25 kHz (±3 dB)
• Nominal impedance: 8 ohms
• Sensitivity: 88 dB (2.83V @ 1 meter full-space, 300-3kHz)
• Recommended amplifier power: 20-300 watts
• 1” Aluminum Dome Tweeter
  • FEA-optimized diffuser for airy and unveiled presentation
  • Aluminum dome for exceptional transient response
• 5.25” Midrange Driver
  • Composite glass-fiber cone with excellent stiffness/mass ratio for high sensitivity and pistonic behavior beyond pass band
  • Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
  • Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
• Triple 6.5” Woofers
  • Long stroke motor and suspension for high output
  • Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior
  • Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
  • Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
• 3-way crossover with premium-grade capacitors, air-core inductors and heavy-trace printed circuit boards
• 2-piece PCB design reduces component interference
• Tweeter-to-Midrange crossover: 2.1kHz (12 dB/octave slopes)
• Midrange-to-Woofer crossover frequency: 300Hz (12 dB/octave slopes)
• Overall Dimensions: 41.1" (H) X 8" (W) X 13.9" (D) (includes grille, feet and binding posts)
• Shipped Dimensions: 46.5" (H) X 14.8" (W) X 19" (D)
• Weight Packaged: 66 lbs (29.9 kg)
